    Sinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker Truck

    Ask Lasest Price
    Brand Name : CLW
    Model Number : clw5312gx43
    Certification : ISO, CCC
    Price : 12250-48620USD/UNIT
    Payment Terms : L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A
    Supply Ability : 300units/month
    Delivery Time : 30 days after received advance payments
    • Product Details
    • Company Profile

    Sinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker Truck

    Sinotruk HOWO 8X4 336HP 24cbm 30cbm Fuel Tanker Truck Diesel Transport Truck


    Description:
    1. Tank material: we can provide carbon steel tanks, stainless steel tanks, manganese steel tanks, aluminum tanks, steel with plastic (or rubber) tanks and plastic tanks.
    2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc butt welding technology, as well as the whole- steel forming a composite.
    3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equip separators [Baffle] to prevent surging of liquid towards bulk head
    4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
    5. Oil punp: gear pump, self-absorption (centrifuge) pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
    6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
    7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
    8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.

    Specifications

    General Technical Parameters
    Overall Dimension11984×2500×3280(mm)Gross Vehicle Weight50000(kg)
    Curb Weight14500(kg)Loading Weight35500(kg)
    Chassis Specification
    Chassis ParametersChassis BrandSINOTRUK HOWO
    CabinRow and half, Left Hand Driving
    EnginePower336HP
    Emission standardEURO II
    Displacement9.726L
    Fuel typeDiesel
    Gearbox10 Forward & 2 Reverse Gear
    Front and Rear Axle load9T/16T
    Wheel Base1800+4600+1350(mm)
    Brake SystemPneumatic
    Steering GearPower Assistant
    Tire12.00R20, 12 Pieces
    Maximum speed80(km/h)
    Tank Body
    ShapeMonoblock Cylinder
    Total Volume(m3)24-30m3
    Tanker Body Material5mm carbon steel
    Manhole Cover∮500mm ,1 set with 1 breather valve
    Bottom Valve1 set
    Discharging Valve1 set ∮80mm discharging valve
    PaintingComplete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
    AccessoriesOne standard tool box

    Reference pictures

    Sinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker TruckSinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker TruckSinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker TruckSinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker TruckSinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker TruckSinotruk Howo 8X4 336HP 24cbm 30cbm Fuel Tanker Truck
