    Shacman H3000 6X4 20m3 22m3 Vacuum Sewer Jetting Truck With Italy Pump

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW5254SQXWC
    Certification : ISO, CCC
    Price : 38520 usd/unit~89660 usd/unit
    Payment Terms : L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A
    Supply Ability : 300units/month
    Delivery Time : Within 30days after received advance payments
    • Product Details
    • Company Profile

    Shacman H3000 6X4 20m3 22m3 Vacuum Sewer Jetting Truck With Italy Pump

    Shacman H3000 6X4 20m3 22m3 Vacuum Sewer Cleaning Tanker Truck with Italy Pump

    Description--Sewer cleaning truck(also called high pressure sewer cleaning truck,sewage suction truck,vacuum truck,vacuum tanker,sucker truck,sewer sucker,hydro-vac,vac-trucks,exhauster truck,sewer vacuum truck,septic suction truck,sewage vacuum truck,sewer cleaning truck,sewage tanker,cessipit emptier,gully emptier,drainage suction truck,vacuum truck,sewage truck,waste vacuum truck,drainage treatment truck,vactor sewage truck,jet vac drain cleaning truck) is one of the new sanitation type vehicle to collect,clean and transport sludge, sewage to avoid secondary pollution.
    Sewer cleaning truck is with advantage of self-suction from discharge, fast working speed, large capacity, convenient transportation suitable for the collection and transport of feces, mud, crude oil and other liquid materials.

    Also with advantage of large suction force and long suction distance, especially suitable for the suction, delivery and discharge of silt in the sewer, especially for the suction of the sewer mud, stones, bricks and other large objects.


    Feature
    --Sewer jetter truck tanker material optional for carbon steel or stainless steel 304;--Tanker thickness 6~8mm,endplate thickness 8mm and baffle 5mm;--Sewer jetter truck pump is optional for chinese brand single weilong pump,water ring suction pump,Italy brand BP,Jurop,Keiser Moro imported brand;--Suction speed less than 10min and and discharge speed less than 8 min;--horizontal suction distance: within 80 meters;--Vertical suction depth:within 9 meters;
    ---Quality chassis , perfect performance
    ---Quality engine , super powerful , reliable performance ,no overhaul within 100,000km.
    ---Nice shape , rational structure
    ---Massive, durable ,perfect performance
    ---Prolonged service time

    Reference picture

    Shacman H3000 6X4 20m3 22m3 Vacuum Sewer Jetting Truck With Italy PumpShacman H3000 6X4 20m3 22m3 Vacuum Sewer Jetting Truck With Italy PumpShacman H3000 6X4 20m3 22m3 Vacuum Sewer Jetting Truck With Italy PumpShacman H3000 6X4 20m3 22m3 Vacuum Sewer Jetting Truck With Italy Pump


    Specification

    Vehicle Description

    Overall dimensions

    9200*2550*3700mm

    GVW

    31000kg

    Curb weight

    13300kg

    Chassis brand

    Shacman

    Traction type

    8*4, left/right hand drive

    Chassis Description

    Chassis model

    SX1315

    Cab

    Sleeper cab, forward control type, low roof, new face, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension, adjustable driver’s seat, air conditioning system, electric windows, central lock.

    Wheelbase

    1800+4575+1400mm

    Tire specification

    12.00R20

    Tire quantity

    12+1 units

    Engine

    Engine model

    WP10.340E22

    Emission level

    Euro 2 (EGR)

    Displacement/output

    8800ml/250kw

    Horse power

    340hp

    Gear box

    Model

    10JSD180

    Number of gears

    10 forward gears& 2 reverse

    Brake system

    Service brake

    Brake gap can be adjusted automatically, double circulation air brake system

    Assistant brake

    Engine exhaust brake

    Park brake

    Potential springs pressing on middle and rear wheels

    Axle

    Front

    MAN 7.5T

    Rear

    MAN 13T-double reduction, ratio 4.769

    Suspension

    Leaf spring

    Fuel tanker

    Type

    Aluminium fuel tanker

    Capacity

    400L

    Total volume
    22,000L
    Fecal tank
    14,000L
    4mm thickness tank
    With a man hole
    With a 360 degree rotation hose on top
    Water tank
    8000L
    5mm thickness tank
    High pressure pump
    Made in china pump : pressure is 22Mpa , flow rated is 215L/min
    Fecal pump
    Water cycle :2BE204
    Theoretical pumping speed of sewage: 20m3/min
    Fecal hose (top)
    The hose length is 5meters , the diameter is 108mm
    The hose can rotation 360 degree
    Back reel
    The reel length is 60meters
    The reel diameter is 19mm

    Why do you choose us for vacuum sewer cleaning truck?


    1.well experienced truck production company to offer high quality and competitive-price sewer cleaning tanker truck to our worldwide customers.
    2.Professional team with international trading experience and strong technical capability to supply you customized truck with effective cost;

    3.Exported to more than 80 countries, such as African market ( Sudan, Angola, Zimbabwe, Liberia, Djibouti, Congo, Kenya, Ghana ect.), Middle East, South Asia and South-America market etc..
    4.One Year Guarantee for trucks and spare parts at factory price whenever needed.

    5.Timely shipment

    6. Overseas training and after sales service is available
