    DN2700mm 70000 Liters LPG Storage Tank For Gas Station

    Ask Lasest Price
    Brand Name : CLW
    Model Number : ASME,CCC,SGS,BV
    Certification : CLW9587el
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 Units/Month
    Delivery Time : 20~30 days after receiving deposit
    • Product Details
    • Company Profile

    DN2700mm 70000 Liters LPG Storage Tank For Gas Station

    35tons LPG Storage Tank 70000 liters LPG storage tank for gas station with best price



    Product Description


    1. Storage medium of lpg gas plant tank : LPG, Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc.
    2. Available tank capacity of lpg gas plant tank : 5m³~200m³,2ton~100tons
    3. Manufacturing standards of lpg gas plant tank : GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008
    4. Optional for lpg gas plant equipments as follows,
    lpg pump and motor,lpg compressor,volume flow meter,filling scales and lpg dispenser,ball valves,check valves,non-return valves,glass valve,strainer,by-pass valve and so on.


    35tons LPG STORAGE TANK
    Volume of Tank70,000Liters
    Filling Weight27930 kg
    Tank Weight14480kg
    Thickness of Shell (mm)14 mm
    Thickness of End plate (mm)16 mm
    Tank Diameter (mm)2700 mm
    External Dimensions (mm) (length x width x height)12714X2728X3318mm
    Material of Tank and Main Pressure PartsCarbon Steel Q345R
    Filling MediumLiquefied Petroleum Gas ( Propane)
    Design Pressure1.77 MPa / 17.7Bar
    Corrosion Allowance1 mm
    Medium Density500 kg/ cbm
    Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China.
    Main parts of LPG Tank
    ItemSpecificationQuantity
    Discharge PipeDN801
    Inflow PipeDN801
    Gas phase balance pipesDN502
    Drain HoleDN501
    ManholeDN4501
    Air-out PipeDN501
    Safety Valve PipeDN802

    Safety Accessories (Included in the quotation):
    Cut-off Valve, Needle Valve, Safety Valve, Magnetic Liquid level meter, Pressure gauge, Temperature Gauge.

    35Tons LPG storage Tank diagram for reference :

    Gas filling station design in Nigeria
    Filling house for cylinders
    Key words: 35tons LPG Storage Tank, 70000 liters Propane Gas tank, 35tons Gas Station
