    40 Tons 80000 Liters Bullet Propane Refill Station

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW180ywyts
    Certification : CCC ISO ASME
    Price : 11250-29560USD/UNIT
    Payment Terms : L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A
    Supply Ability : 300units/month
    Delivery Time : 30 days after received advance payments
    • Product Details
    • Company Profile

    40 Tons 80000 Liters Bullet Propane Refill Station

    40Tons 40MT 40T 80000Liters Bullet Porpane Station Tank lPG gas refilling plant for Nigeria

    Function

    --LPG Storage tank (also called lpg tank, lpg gas tank,lpg gas storage tank,lpg storage tank,gas storage tank,cooking gas tank,lpg plant tank,filling station tank,lpg storage tank for sale in nigeria,propane tank,propane station tank) is a professional product for storing LPG or propane gas,belonging to special equipment and vessels and require special material,third-class pressure vessel with Q345R material.Q345R is one of ASME standard material.


    -- LPG Storage tank can be divided into various types as follows,

    ★Above ground bullet LPG tank and underground bLPG Storage tank;

    According to tank size,there are 5,000liters to 200,000liters LPG Storage tank for option;

    ★Vertical bullet LPG tank and horizontal LPG Storage tank.


    Feature

    --The welding joints, welds, tank heads and geometric positions of each pressure element are strictly inspected by X-ray;

    --non-destructive testing and magnetic particle inspection test for each LPG Storage tank;

    --Design pressure of LPG Storage tank: 1.77Mpa;

    --hydraulic testing pressure:2.21 Mpa;

    --Corrosion allowance: 1mm;

    -Optional for tank accessories and lpg gas station equipments such as safety valve,globe valve,ball valve,pressure gauge,thermometer,magnetic level guage or rochester float-ball level gauge,lpg pump and motor,lpg compressor,lpg flow meter,cylinder filling scales,strainer,glass valve and so on.


    40 Tons 80000 Liters Bullet Propane Refill Station40 Tons 80000 Liters Bullet Propane Refill Station

    Parameter of 40Tons 80cbm LPG Storage Tank
    ITEMPARAMETERITEMPARAMETER
    Volume80cbmThickness of Shell16mm
    Tank MaterialQ345RThickness of End plate18mm
    Overall Size11166*3132*3722mmTank Net Weight17000kg
    Tank Diameter3100mmLoading Capacity31920kg
    Design Pressure1.77MpaGas Density420kg/M3
    Hydraulic Test Pressure2.22MpaCorrosion Allowance1mm
    Design Temperature-20℃~50℃Heat TreatmentBulk
    Vapor OutletDN50Gas OutletDN50
    Life time15 years
    Accessories
    ModelItemQtyJunction surface
    J41N-2.5-50Stop Valve DN506RF
    J41N-2.5-25Stop Valve DN252RF
    J41N-2.5-100Stop Valve DN1001RF
    J24W-320-DN6J24W Needle Valve M20*1.51
    HG21584-95Magnetic plate level Gauge UZFAL-2.5RF-3040-0.51RF
    A42F-25-100Safety Valve DN1001RF
    Y-100TPressure Gauge M20*1.5 1.5degree 0~4Mpa1
    WTQ-280Thermometer M33*2 2.5 degree1-40℃~60℃


    FAQ

    ★How can I get a sample of propane tank to check your quality?

    Answer:Due to the propane tank size,sample can not be sent to your country.But we have supplied a lot of propane tanks to customers in many countries,you can go and check our tanks if you are nearby,Or welcome to visit our factory in china and check the quality by yourself.


    How long can I expect to get the propane tank ?

    Answer:20~30 working days after receiving deposit at account.

    What's your payment term?

    Answer:40% deposit by T/T and balance by T/T before shipment.We also accept 100% irrevocable LC at sight.

    ★When can I get the price of propane tank ?

    Answer:we will contact you as soon as receiving your inquiry by email or message in 24 hours.


    ★Does your propane tank have warranty service? How long is the warranty period?

    Answer:Yes,lifetime of propane tank is 20 years.
