    Shacman F3000 6*4 10 Wheels Prime Mover Crane Truck 70T Haulage Capacity

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW0581GS
    Certification : BV, SGS, CCC
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 1000 Unit/Month
    • Product Details
    • Company Profile

    Shacman F3000 6*4 10 Wheels Prime Mover Crane Truck 70T Haulage Capacity

    China Hot Sale Shacman F3000 6*4 10-Wheels 70 Tons 420HP CNG Tractor Head


    Product Description


    1. Based on STR technology from Austria
    2. Cabin:Four point s suspension HOWO Cabin with spring and air shock absorber, VDO panel
    4. Engine:371HP WD615 STR engine ( from 290hp - 420 hp you can chose )
    Type: Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling.
    5. Front axle: HF9 STEYR technology front steering axle
    6. Rear axle: AC16 16ton STEYR technology double reduction hub reductor driving axle
    7. Steering: ZF8098, driver sit at the left hand side
    8. Loading capacity: 30-40ton
    9. Designed for tough road condition especially for African countries
    10. Punctual delivery time
    11. Excellent OEM spare parts supply for after-sales service.


    Product Specification

    Traction type
    6X4

    Driving type

    Left Hand Driving

    Overall Dimension(LxWxH)

    7475x2490x3730

    Wheel base(mm)

    3775+1400mm

    Curb weight(kg)

    8800

    Total mass(kg)

    25000

    Traction force(kg)

    40000

    Engine
    Steyr technology, made in China

    WP12NG350E40

    Diesel, 4-stoke Direct injection,
    6-cylinder in line, radiator, turbo-charging

    Displacement(L)

    11.596

    Bore X stroke (mm)

    126mm/155mm

    Max speed(km/h)

    99

    Max power(kw/rpm)

    350HP/2200(CNG)

    Max torque(Nm/rpm)

    1400NM@1400-1600/rpm

    Emission

    EURO4

    Gas tanker(L)

    8×120L+4×80L

    Gearbox

    Brand

    Fuller (Fast)

    Model

    12JSD180T

    Shift mode

    12 forward speeds;
    2 reverse speeds

    Steering system

    Model

    ZF technology

    Clutch

    Model

    430 Diaphragm type

    Frame

    850×300×(8+5)mm

    Front axle

    7.5T MAN front non-driving steering axle

    Middle and Rear axle

    13TMAN double reduction driving axle

    Tyre

    12.00R20

    Ratio

    4.266

    Number of tyre

    10+1 spare

    Fifth wheel

    3.5"

    Suspension

    Leaf spring type

    Front/rear: 10/12

    Color

    optional

    Electrical

    Battery

    2x12V/135Ah

    Generator

    28V-35A

    Starter

    5.4Kw/24V

    Cabin

    Shacman F3000 Lengthen high roof cabin
    with double sleeper, with A/C, ABS.

    Company Introduction

    Our Overseas Exhibition


    Sales Service

    ①Pre-sales Service: Communicate with customers, analyze their needs. Quick feedback to solve your questions.
    ②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
    ③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
