    Dongfeng Cummins Sewage Suction Tanker Truck / Vacuum Cleaner Truck 3CBM To 5CBM

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW5100GXW2
    Certification : ISO, CCC
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500units/month
    Delivery Time : 30-35days after received advance payments
    • Product Details
    • Company Profile

    Dongfeng Cummins Sewage Suction Tanker Truck / Vacuum Cleaner Truck 3CBM To 5CBM

    Dongfeng Cummins 3CBM to 5CBM Sewage Suction Truck with Self Dump System


    Product Description


    1. Vacuum Sewage Suction Truck for city sewage cleaning and delivery.


    2. High quality ISUZU Brand or Hyundai Brand, as well as famous chinese brand Sinotruk, JAC, Dongfeng, etc


    3. Long last wind cooling vacuum pump in Word Best Brand Italian Jurop pump.


    4. 10,000liter tank capacity which can carry about 8Ton sewage.


    5. Self Tipping system with rear openning door, With rubber pipe for rust resistant.


    Description3cbm 4cbm 5cbm Fecal Suction Truck Sewage Suction Truck Vacuum Truck
    Drive Model4X2
    ChassisEQ1060
    Number of axles2
    Vehicle Main DimensionsDimensions(L x W x H)(mm)5995×2000×2550
    Wheel base (mm)3300
    Overhang (front/rear) (mm)1032/1663
    Wheel track (front/rear) (mm)1506/1466
    Approach/Departure angle(°)19/14
    Weight in KGSGVW.6495kg
    Curb Weight4200kg
    Max. driving speed(km/h)90
    EngineModelCY4102-C3F
    Type4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
    Horse Power(HP)99HP
    engine capacity(ml)3856
    Emission standardEuro III
    Gearbox5 forwards & 1 reverse
    ClutchReinforced diaphragm clutch
    Steering GearPower steering, hydraulic steering with power assistance
    Fuel tank (L)100
    Tire7.00-16 tire , 6 + 1(spare)
    Brakesdual circuit compressed air brake
    Tank
    MaterialQ235A Carbon steel
    Medium Density800kg/m³
    Loading Capacity (m³)4
    Overall dimensions(mm)3200×1100×1100
    Thickness(mm)5
    Standard
    Equipment
    Equipped with vacuum pump
    rating rotate speed 1400r/m,
    min rotate speed>800r/m,
    max suction lift>6m, vacuum>500mmHg,
    Equipped with power take off, transmission shaft,
    fecal tank, pipe network, fecal pipe for observing & cleanout equipment
    Time for full suction<5min

    Products Show


    Sales Service

    ①Pre-sales Service: Communicate with customers, analyze their needs.
    ②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
    ③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.


    FAQ

    Q1: What kinds of Sewer cleaning truck I can order from your company?

    A: We can supply normal sewege suction truck and high pressure sewer flushing and sewage suction truck, the difference between those two kinds of sewer cleaning truck are water tank and high pressure water pump. Basically speaking, we can supply 5CBM to 35CBM sewer cleaning truck as per our customer's request. Pls contact with us for more technical details discussion.


    Q2: What is your production standard of Mobile Advertisement Truck products? Whether your Mobile Advertisement Truck can export to USA, Canada and Europen countries?

    A: Our CBU Sewer cleaning truck is produced as per China GB local standard; We can export super structure to those market, we ever exported 50 units sewage suction truck's super structure and 20 units sewage suction sewage trailer to Australia market in the past two years.


    Q3: Can we adopts International brand sewage pump for sewage suction truck?

    A: Sure, we already cooperated with Italy Jourp and a Germany brand.


    Q4: What about warranty?
    A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.


    Q5: Where is your factory? How far from Shanghai to your factory?
    A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
