6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping

HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping from wholesalers

    Buy cheap 6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping from wholesalers
    • Buy cheap 6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping from wholesalers
    • Buy cheap 6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping from wholesalers
    • Buy cheap 6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping from wholesalers
    • Buy cheap 6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping from wholesalers

    6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping

    Ask Lasest Price
    Brand Name : clw
    Model Number : clw5100A8LAY
    Certification : CCC,SGS,BV
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram, D/A, D/P
    Supply Ability : 500 Units per month
    Delivery Time : 30 days after receiving deposit at account
    • Product Details
    • Company Profile

    6mt Road Cleaning Vaccum Isuzu Sweeper Truck High Efficiency Sweeping

    6mt isuzu road cleaning truck 6ton vaccum road sweeper truck for Cambodia

    Product Description


    1. Purpose: road cleaning truck also named as road cleaning truck is a new high-efficient sweeping equipment which has multi-functions like road washing,sprinkling,garbage collecting and transportation...Sweeper truck can be widely used in main city road,airport road,residential area road,park,terminal,square,cement factory,power plant and etc.


    2. Main parts: stainless garbage bin,water tank,Italy hydraulic oil pump,germany magnetic valve,french Schneider eletronic control unit,auxiliary engine,suction panel,sprinkler system,brush.


    3. Struture of road cleaning truck:two sweeping brushes in middle+wide suction nozzle and high pressure sprinker nozzles in middle+high pressure sprinkler nozzle at left and right side".


    4) road cleaning truck adapts Interligent one-key control technology,all operations are completed in the cabin.


    5) On the basis of one-key control technology, the manual throttle control system of the auxiliary engine is added, which can independently adjust the throttle size according to the road condition, effectively enhancing the cleaning effect and reducing fuel consumption.


    6) As many as 16 voice prompts and music alarm can broadcast of various safety tips and failure points accurately.


    Specifications of 6mt isuzu road cleaning truck 6ton vaccum road sweeper truck for Cambodia


    Cabin

    Driving type 4x2 LHD

    single row,with A/C ,with two seats,audio with USB,

    Vehicle Main DimensionsOverall dimensions (L x W x H)mm7600×2300×2700
    Wheel base (mm)4175
    Wheel track (front/rear) (mm)1680/1650
    Approach/Departure angle(°)17/12
    Weight in KGSTare Weight7420
    payload2440
    Front axles loading capacity1x3360
    Rear axles loading capacity1x6695
    Max. driving speed(km/h)110
    EngineBrandISUZU
    Model4HK1-TCK40
    Horse Power(HP)189
    Emission standardEuroV
    Gearbox6 forwards & 1 reverse
    Steeringleft hand drive
    Tire8.25-16,6 tires with one spare
    Max. Cleaning Width3M
    Sweeper Speed3~20 km/h
    Max. Cleaning Capacity60000 m2/h
    Max. Suction grain size≥110mm
    Dumping angle≥45°
    Hopper5000liters,double layer,Stainless steel inside
    Water tank6000Liters
    Auxiliary EngineModel&ManufacturerJIANGLING JX493ZQ
    TypeFour-injection,water-cooling,turbo-charged,diesel engine
    Power77hp/3600r/min
    Max. Rotation Speed2400r/min
    Oil type0# Diesel,share the same fuel box with chassis
    AeratorTypeHigh pressure centrifugal Aerator
    Curb rotation speed2600-2900r/min
    Driving modelDriven by auxiliary engine and transferred by transmission parts,clutch and belts
    Hydraulic SystemTypeelectro-hydraulic Centralized Control
    Main partsGear pump,gerotor motor,hyraulic oil cylinder,magnetic valve,manual pump
    Overflow pressure14MPa
    Hydraulic oil typeL-HV46(when temperature is 30℃-5℃)
    L-HM46(when temperature is 5℃-40℃)
    Hydraulic oil box70L
    Water sprinklingMain partsWater pump,water filter,sprinkler,water box
    Electrical systemCon-structureTwo batteries(in series)
    Voltage24V
    Battery model12-80A.H
    Sweeping SystemType

    Fours brushes installed between front and rear axle,driven by gerotor motor.

    Left and right brushes are controlled to lift up and down separately.

    Rear brushes and suction nozzle are gang controlled for up and down.

    Sweeper Diameter900mm
    Sweeper rotation speed80r/min
    Sweeper angle adjustmentForerake 4°-6°and extroversion 2°-4°
    Suction NozzleTypeU-shaped
    Nozzle diameter200mm
    Nozzle ground clearance when operation5-10mm

    Our Service

    • Quick feedback to solve your questions

    • Professional engineering and production team

    • Related Accessories and spare parts offered,no future worries

    • Regular customer after-sale visiting

    • Free technical staff training and guidance

    • Reasonable price and good quality

    • Quick delivery and shipment


    FAQ


    Q1: What kinds of sweeper trucks I can order from your company?


    A: There are various sizes of sweeper trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.


    Q2:: Have you supplied sweeper products to any overseas companies?


    A: Yes,with need of cleaning cities,we offered sweeper trucks to many Africa and south-east Asian countries.


    Q3 What about warranty?


    A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.


    Q5: Where is your factory? How far from Shanghai to your factory?


    A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
