    Dongfeng 10 Ton Refrigerated Truck , -15 ℃ Refrigerated Delivery Truck With Rear Hydraulic Loading Plate

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW5160
    Certification : ISO, CCC,SGS,BV
    Price : negotiable
    Payment Terms : D/A, D/P, T/T, Western Union, Western Union, L/C
    Supply Ability : 500 units/month
    Delivery Time : 30-35 days after received deposit
    • Product Details
    • Company Profile

    Dongfeng 10 Ton Refrigerated Truck , -15 ℃ Refrigerated Delivery Truck With Rear Hydraulic Loading Plate

    10 ton refrigerated truck Dongfeng -15 ℃ refrigerator box truck with rear hydraulic plate

    Product Description


    1. Purpose of 10 ton refrigerated truck : It used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.

    2. Main parts of 10 ton refrigerated truck: Refrigerating unit and control system.

    3. Features of 10 ton refrigerated truck: International chassis brand and International refrigerating unit brand for optional.


    Spec of 10 ton refrigerated truck


    ConditionNew condition/Left hand drive/4x2

    Chassis

    BrandBrand
    Curb weight(kg)9000 kg
    Payload(kg)7000 kg
    Wheelbase(mm)5600 mm
    Dimensions(mm)9990*2490*3850 mm
    Front/Rear axle loading(kg)6000/10000 kg
    Front/Rear overhang(mm)1430/2960 mm
    Wheel track (front/rear) (mm)1880/1800mm
    Approach/Departure angle(°)20/8
    Max. driving speed(km/h)90 km/h
    ClutchReinforced diaphragm clutch
    BrakesHydraulic oil brake
    Steering GearPower steering, hydraulic steering with power assistance
    TireQuantity6pcs with one spare tire
    Specifications9.00R20
    TransmissionManual type, 5 Forwards and 1 reverse
    CabSingle row seat, Tiltable. It can accommodate three people. With air conditioner. With Air deflector
    EngineBrandCummins
    ModelB180 33
    Fuel typeDiesel
    Horsepower(HP)180 HP
    Emission standardEuro 3
    Upper
    Box

    1. Box Size: 7400×2280×2400 mm

    2. Box Material, glass epoxy in the surface; Foam in the middle , side ,top ,front ,rear thickness 80mm/100mm; Inside bottom: Aluminum pattern plate

    Refrigerating System

    1. Working temperature setting range: to -18℃

    2. Refrigerating unit brand and model: USA brand Thermo King,CARRIER

    RemarksColor is optional

    Products Show



    Main Structure of 10 ton refrigerated truck


    1) Van box material:Chinese high quality glass steel,optional for color plate,stainless steel,aluminum alloy steel

    2) Refrigerator unit system:Chinese renown brand like HANXUE,HUATAI,US brands such as CARRIER,THMOKING,south korean brand such as DONG IN THERMO CO.,LTD

    3) Temperature setting ranges from -5 ℃ to -15 ℃ and available for outer electricity source

    4) Stainless steel knock

    5) Hooks for hanging meat

    6) stainless steel or glass steel bottom plate with ventilating slot

    7) Temperature controller in cabin and easy for operation



    Our Service

    • Quick feedback to solve your questions

    • Professional engineering and production team

    • Related Accessories and spare parts offered,no future worries

    • Regular customer after-sale visiting

    • Free technical staff training and guidance

    • Reasonable price and good quality

    • Quick delivery and shipmen



    FAQ


    Q1: What loading weight 10 ton refrigerated truck I can order from your company?

    A: We can supply 990kg-40tons refrigerated truck, if you need big size refrigerated semi trailer, we also can supply it, there have 2 axles and 3 axles 40tons to 60tons refrigerated semil trailer for optional.


    Q2: What is your production standard of refrigerator truck and trailer? Whether your refrigerated truck and trailer can export to USA, Canada and Europen countries?

    A: Our CBU refrigerated truck and trailerg truck is produced as per China GB local standard; We can export super structure to those market, we ever exported refrigerated truck super structure and refrigerated semi trailer to Europen countries before.


    Q3: Can we adopts International brand refrigerating unit for refrigerated truck and semi trailer?

    A: Sure, we can supply USA brand Thermo King, Carrier and South Korea brand DONG IN THERMO.


    Q4: What about warranty?
    A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.


    Q5: Where is your factory? How far from Shanghai to your factory?
    A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
