    20T Propane Transport Trailer , Horizontal Bullet Propane Delivery Truck 40000 Liter Capacity

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW9390
    Certification : ASME,CCC,BV,SGS
    Price : negotiable
    Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 units/month
    Delivery Time : 30 days after receiving deposit
    • Product Details
    • Company Profile

    20T Propane Transport Trailer , Horizontal Bullet Propane Delivery Truck 40000 Liter Capacity

    20T Propane Deliver Tank Trailer in 40000Liter Horizontal Bullet Tanker Capacity


    Product Description


    1) LPG Propane Tank Perfect Choice for Narrow Road and Crowded Area Transport

    2) Designated Country: Bangladesh, Mongolia, Vietnam, Mymmay, etc

    3) Level Gauge: ROCHESTER, MEC, REGO, etc

    4) Major Valves: Safety Release Valve,Emregency Cut-off Valve, Ball for Liquid & Vavle,

    5) Gauge: Temperature Gauge, Pressure Gauge,

    6) Optional: LPG Flowmeter, LPG Discharging Hose in 4meters


    Specifications of 20T Propane Deliver Tank Trailer in 40000Liter Horizontal Bullet Tanker Capacity


    40 CBM LPG Tanker Trailer
    Volume of Tank40,000 Liter
    Filling Weight18,000 kg
    Tank Weight13,415 kg
    Tank Diameter (mm)2200 mm
    External Dimensions (mm) (length x width x height)13000 x 2500 x 3990 mm
    Material of Tank and Main Pressure PartsQ345R
    Thickness of Shell (mm)12 mm
    Thickness of Endplate (mm)12 mm
    Filling MediumLiquefied Petroleum Gas ( Propane)
    Corrosion Allowance1 mmFilling Ratio500-560 kg / cbm
    Design Pressure1.61 MPa / 16.1 BarHydraulic Test Pressure2.22 Mpa / 22.2 Bar
    Working Pressure1.61 Mpa / 16.1 BarAir Tightness Test Pressure1.71 Mpa / 17.1 Bar
    Chassis Specification
    ItemSpecification
    Main BeamsHeavy duty and extra durability designed; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes
    Axle2 pieces of 13Ton German Brand BPW Axle,
    Landing GearJOST Two-speed, manual operating, heavy duty landing gear
    King PinJOST 2”standard bolt-in king pin
    SuspensionGerman design mechanical suspension
    Pneumatic Braking SystemWABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks.
    Tire11.00R20 tire, 8 Pieces with 1 Spare
    PaintingComplete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
    Nozzle Specification
    Liquid Inlet & Outlet Coupling2 No, 2" Flange Type
    Vapour Coupling1 No, 2" Flange Type
    Safety Relief Valve1 Nos., 2” NPT,
    Excess flow internal valve for liquid inlet &outlet2 No., 2” NPT,
    Excess flow internal valve for vapor1 No., 2” NPT
    Pressure gauge1 No., 3/8”or ¼’’NPT, 4” Dial 0-35 Kg/cm2,
    Needle valve for pressure gauge1 No., 3/4” NPT,
    Temperature gauge1 No., ½ ” BSP,4” Dial 0-100 0C,
    Rotor gauge1 No., 1” NPT,
    Ball valve for liquid inlet & outlet2 No., 2” Single Piece Full Bore Class 300
    Ball valve for vapor line1 No., 2 ” Single Piece Full Bore Class 300
    ManholeDN 450MM



    Our Service

    • Quick feedback to solve your questions

    • Professional engineering and production team

    • Related Accessories and spare parts offered,no future worries

    • Regular customer after-sale visiting

    • Free technical staff training and guidance

    • Reasonable price and good quality

    • Quick delivery and shipment


    FAQ


    Q1: What kinds of LPG products I can order from your company?


    A: We specialize in producing 5CBM to 200CBM LPG above ground storage tanker, 5CBM to 120CBM LPG underground storage tank, 5CBM to 38.5CBM LPG tank truck, 5CBM to 25.5CBM LPG dispenser truck/LPG bobtail truck, 40CBM to 61.9CBM LPG semi trailer and 5CBM to 50CBM LPG Skid Station/LPG mobile filling station etc. Please feel free to contact us for details.


    Q2: What is your production standard of LPG products? Can you manufacture your products under ASME standard?


    A: Usually our LPG products adopts GB-150/China standard, there ASME standard for optional. Yes, we can do ASME standard and our ASME standard as per DIV 01 SEC VIII.


    Q3: Have you supplied LPG products to any renowned companies?


    A: Our group company is a regular strategic partner of some big gas companies. We have supplied many storage tanks and semi trailer for them with different sizes,such as ENOC,AARANO,NIPCO,LAKEGAS...The biggest size tank we ever provided is 200m3 LPG storage tanks,.


    Q4: What about warranty?


    A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.


    Q5: Where is your factory? How far from Shanghai to your factory?


    A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
