Dongfeng 14cbm Road Sweeper Truck Debris Collection Street Cleaning Machinery

14 CBM Dongfeng Tianjin Vacuum Cleaning Sweeper Truck

Sweeping Mode:

Road Sweeping mode, which only uses the sweeping brush to sweep the road.

Working Flow Chart:

Auxiliary Engine----Hydraulic Oil Pump-----Left & Right Sweeper Disc----Left & Right Sweeping Brushes

Auxiliary Engine--- Fan Working----Dust Tank, Suction Pipe & Sution Nozzle---High Speed Air Flow bring garbage Inside

Washing and Sweeping mode:

Road Sweeping and road cleaning functions are turned on at the same time.

Working Flow Chart:

Auxiliary Engine----Hydraulic Oil Pump-----Left & Right Sweeper Disc----Left & Right Sweeping Brushes

Auxiliary Engine--- Fan Working----Dust Tank, Suction Pipe & Sution Nozzle---High Speed Air Flow bring garbage Inside

Auxiliary Engine---Auto Clutch—High Pressure Water Pump---Delivery Water----Left & Right Cleaning Nozzle

1. This top quality CLW GROUP designed product is loaded with unique features which greatly increase safety and productivity and is the perfect solution for Industry, Councils and Contractors for removing litter, detritus and debris from hard and soft surfaces, including tight corners and around street furniture.
2. Modern computer controlled motors, automatic multi speed suction power, self-cleaning air filters with option and a silent on-board pressure washer sets this new machine completely ahead of any competition.

3. CLW GROUP’s commercial parking lot and garage facility sweeping and cleaning division caters to your property’s needs and schedule. Our mission is to make sure that your parking lots create a positive impression for your customers, employees, and tenants – all while maintaining a low environmental impact on stormwater runoff and improving surface durability and longevity.

Product			Dongfeng Kingrun Cleaning Sweeper Truck
Model No.			CLW5180TXSD6
Chassis Model No.			DFH1180EX8 DAFC
Standard			GB3847-2005, GB17691-2018 Euro 2-Euro6
Engine	Truck Engine	Engine Model	B6.2NS6B210 Cummins
		Power(kw)	154
		Hp(ps)	210
		Displacement (ml)	6200
	Deputy Engine	Sweeper Engine Model	B170 33
		Power (kw)	125
		HP(ps)	170
		Displacement(ml)	5900
	Diesel Type		Same Type of Diesel as truck
Truck Specification	Overall Size mm		L 8550* W2480* H3130
	Wheel Base(mm)		5000
	Tire		275/80R22.5 18PR
	Tire Quantity		7(include 1 Spare)
	Wheel Track	Front(mm)	1876
		Rear(mm)	1820
	Passenger Allowed		3 person
	Overhang Front/Rear (mm)		1430/2220
	Approaching Angle		17°
	Departure Angle		25°
	Ground Clearance(mm)		320
	Loading Weight(kg)		6870
	Truck Weight(kg)		11000
	Gross Vehicle Weight (kg)		18000

Sweeping Specification	Garbage Box( m³ )		7,000L Stainless Steel
	Water Tank( m³ )		9,000L Stainless Steel
	Sweeping Width (mm)		2800-3200
	Sweeping Speed (km/h)		3-15
	Truck Speed in cleaning (km/h)		15-20
	Sweeping Capacity (m²/h)		48000
	Suction Capacity	Density(g/cm³)	2.0
		Weight (kg)	1.5
		Max Diameter (mm)	≥100
	Garbage Box Dumping Angle		≥45°
	Sweeping Efficiency		≥96%
	Working Noise(db)		< 88 Meet GB7258 Standard

Dust Control System	Spraying Type		Low Pressure Fog Type
	Main Components		Imported high pressure pump water filter pipeline stainless steel spray frame high pressure nozzle
	High Pressure Water Pump		CPX036
	Installation Position	Sweeping	Left & Right Sweeper
		Suction	Suction Pan Inside
	Control Type		Electronic control, one key operation

Hydraulic System	Type	Open Type, electric control
	Main Components	Gear pumps, Cycloid Motors, Hydraulic Cylinders, Solenoid Valves, Manifold Blocks, High-pressure Pumps,
	Cycloid Motors	Sanyo Motor
	Gearbox	Changyuan Machine
	Hydraulic Cylinder	Hi-Pressure(Italian Brand)
	Cylinder Sealing	DingJi
	Hydraulic Oil Pipe	Guangzhou Tianhe
	Solenoid Valves	Hi-Pressure(Italian Brand)
	Pressure Gauge	IMT (Shock Proof)
	Oil Filter	Sofima Brand
	Hydraulic Pressure	10-12 Mpa
	Hydraulic Tank	≥60 L
Electrical System	System	Chassis & Deputy Engine Electrical System
	Chassis Power Voltage (V)	24
	Working System Power Voltage(V)	12
	Control Panel	Auxiliary engine tachometer, auxiliary engine water temperature gauge, oil temperature alarm device, various operation control switches
	Control Switch	Schneider Shanghai
	PLC	BaichaoFu
	Braker	Higer
	Battery	12V-70A.H (2 units in parallel)
Fan System	Type	High-pressure Centrifugal Fan
	Brand	Changsha Lianyue
	Rated working speed	2700 r/min
	Transmission type	Auxiliary engine, clutch, high temperature resistant A-belt drive with teeth (4)
	Fan Belt	Zhejiang Sanshili
	Automatic clutch	centrifugal type, imported material
	Air Volume	5000 ~ 7800 (m3/h)

Truck Photos:

Our Service

Quick feedback to solve your questions
Professional engineering and production team
Related Accessories and spare parts offered,no future worries
Regular customer after-sale visiting
Free technical staff training and guidance
Reasonable price and good quality
Quick delivery and shipment

FAQ

Q1: What kinds of sweeper trucks I can order from your company?

A: There are various sizes of sweeper trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2: Have you supplied sweeper products to any overseas companies?

A: Yes,with need of cleaning cities,we offered sweeper trucks to many Africa and south-east Asian countries.

Q3 What about warranty?

A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?

A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
