    Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

    Ask Lasest Price
    Brand Name : CLW
    Model Number : clw5252WYYGC
    Certification : ISO, CCC
    Price : Negotiable
    Payment Terms : L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A
    Supply Ability : 300units/month
    Delivery Time : 30 days after received advance payments
    • Product Details
    • Company Profile

    Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

    Oil tamker truck is mainly used or storage and transport oil, diesel, gasoline, kerosene, stainless steel fuel bowser etc.

    Product advantages
    1. Tank material: we can provide carbon steel tanks, stainless steel tanks, manganese steel tanks, aluminum tanks, steel with plastic (or rubber) tanks and plastic tanks.
    2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc but welding technology, as well as the whole- steel forming a composite.
    3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equipped separators baffle to prevent surging of liquid towards bulk head.
    4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
    5. Oil punp: gear pump, self-absorption pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
    6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
    7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
    8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.

    Specification

    General Technical Parameters
    Overall Dimension11970*24960*3025(mm)Gross Vehicle Weight36000(kg)
    Curb Weight11450(kg)Loading Weight25000(kg)
    Chassis Specification
    Chassis ParametersChassis BrandSINOTRUK
    CabinRow and half, right Hand Driving
    EnginePower371HP
    Emission standardEURO2
    Displacement9726ml
    Fuel typeDiesel
    Gearbox10 Forward & 2 Reverse Gear
    Front and Rear Axle load9T/16T (8x4 Driving type)
    Wheel Base1800+4625+1350(mm)
    Brake SystemPneumatic
    Steering GearPower Assistant
    Tire12.00R20, 12 Pieces+one spare tire
    Maximum speed85(km/h)
    Tank Body
    ShapeMonoblock Cylinder
    Total Volume(m3)25m3
    Tanker Body Material5-6mm carbon steel
    Manhole Cover∮500mm ,1 set with 1 breather valve
    Bottom Valve1 set
    Discharging Valve1 set ∮80mm discharging valve
    PaintingComplete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
    AccessoriesOne standard tool box

    Reference photos

    Key words: Fuel bowser truck, fuel tanker truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, diesel dispensing truck, oil delivery truck, Mobile Fuel Truck, oil loading truck, oil refuelling truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, fuel bowser, diesel dispensing truck.


    It can be divided into many compartments to transport different medium, which will make your transportation easy and safe.

    Warranty
    1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
    2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
    3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.


    Spare Parts
    1. Supplying quick-wearing parts at the truck delivery.
    2. Good quality parts produced by the truck manufacturing factory.
    3. Only charge cost price for customer convenience.


    After Sales Service
    Email & Phone call tracking for each truck on timely manners.

    Shipment
    Land transportation or Ship by bulk cargo ship, container, roro ship
