    24cbm LPG Bobtail Truck Propane Dispenser Delivery Truck

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW5120WY
    Certification : ASME,CCC,BV,SGS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 Unit/Month
    Delivery Time : 30-35 working days
    • Product Details
    • Company Profile

    24cbm LPG Bobtail Truck Propane Dispenser Delivery Truck

    24cbm LPG Bobtail Truck Propane Dispenser Delivery Truck

    1. LPG tank truck is a pressure vessel vehicle that combined with the chassis, 100% X-ray radiographic tested tanker, safe valve, emergency cutting valve, themometer, liquid level meter, pressure gauge, gas dispenser and gas pump, which used for transporting or filling the gas to different gas station.The cubage could be from 5cbm to 37cbm.

    2.ASME and ISO manufacture standard are both available.


    Description:

    1. Chassis brand: Dongfeng, Howo, Foton, I-suzu, etc.
    2. Tank volume available: 5000 liters, 5500 liters, 8000 liters , 10000 liters, 12cbm, 15cbm , 18cbm, 20cbm, 30cbm,etc
    3. Material of the lpg tank: Q345R, Q370R, ASME material SA516, SA612
    4. Refill system: lpg pump+ flow meter+ fiillin pipe +filling gun / lpg pump+ lpg dispenser+filling pipe+filling gun
    5. Application: Fill gas for small lpg skid station or lpg cylinders

    Product Specification:

    Item No.Parameters
    Overall Dimension10590* 2495* 3350mm
    Gross Vehicle Weight25000kg
    Curb Weight11120kg
    Wheel Base4325+1350mm
    CabinLeft Hand Driving, 2 Passengers Allowed, with Air Conditioner
    EngineWD615.62 Diesel Engine, 6 Cylinder in line. Four Stroke.water-cooling,supercharged and mid-cooling,Direct injectio
    Engine horsepower336HP Euro II
    Max Driving Speed90 km/h
    Gear Box10 Forward Gear & 2 Reverse Gear
    Tire12R22.5 Tubeless Tire (10 pieces with one spare)
    Tank Capacity24 CBM / 24,000 Liters
    Filling Weight10000kg
    Filling ContentLiquefied Petroleum Gas (Propane)
    Tank MaterialQ345R, 10mm Thickness for Tank Body & End plate.
    Standard Equipment1 Safety Valves,1 Ball floating Level Gauge,
    1 Pressure Gauge, 1 Thermometer, 2 Emergency Shut-off Valve, 1 Tool Boxes, Anti-static Grounding Tape, with 1 valve boxes,
    SpecificationDesigned Pressure: 1.61Mpa / 16.1 Bar
    Hydraulic Test Pressure: 2.21 Mpa / 22.1 Bar
    Air Tightness Pressure: 1.61Mpa / 16.1Bar
    Medium Density: 500-590 kg/m3
    Working Temperature: under 50 centi-degree
    Corrosion Allowance: 1mm
    Filling System
    1. Hydraulic Drive 2" Truck Pump.
    2. Liquid Control Flow Meter to Record Filling Volume
    3. LPG Filling Hose for Cylinder


    Reference Photos


    Two Types of Dispenser for Optional:

    Related Products:


    JAC 8*4 34.5cbm LPG Tank Dispenser Truck 17 Tons 18 Ton With Gas Filling Machine

    After-sales Service

    1. Provide English operation manual and Instruction videos.
    2. One year free warranty for major 3 components: engine, gearbox, axles; One set of easily worn spare parts of truck chassis for free; Spare parts supplied at factory price whenever needed.
    3. Aftersales service whenever needed. Our engineers will go to customer's country to assist the installation and operation if order QTY.is more than 10 units.


    FAQ


    Q1: What kinds of LPG bobtail truck I can order from your company?

    A: We can supply different sizes LPG bobtail truck as client's request. Basically speaking, we can supply 5CBM to 38CBM type. Pls contact with us for more technical details and discussion.

    Q2: What is your production standard of LPG bobtail truck?
    A: Transportable Pressure Vessel Safety Technology Supervisory Regulations and GB150.1~4-2011Transportable Pressure Vessel Safety Technology Supervisory Regulations and GB150.1~4-2011

    Q3: Can we adopts International brand parts or accessories for LPG
    bobtail truck?
    A: Sure, we already cooperated with many international brand suppliers.

    Q4: What about warranty?
    A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

    Q5: Where is your factory? How far from Shanghai to your factory?
    A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to Wuhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
