3 Axle 45T 50T 60T 40ft Warehouse Cargo Fence Semi Trailer

Ask Lasest Price
Brand Name :	CLW
Model Number :	CLW20211214
Certification :	ISO9001, CCC, BV, SGS
Price :	Negotiated
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	500 units per month
Delivery Time :	30-35 days after receiving the deposit

Add to Cart

Product Details
Company Profile

3 Axle 45T 50T 60T 40ft Warehouse Cargo Fence Semi Trailer

40ft 3 axle 45Tons 50Tons 60Tons Warehouse Cargo Fence Semi Trailer

Chengli Special Automobiel Co., Ltd. as the professional semi trailers supplier, mainly offer the heavy haul lowbed trailers. front detachable goose neck lowboy trailers, container side lifter trailers and customized extendable low bed trailers, fuel cement tanker or acid tanker trailer, end and side tipper trailers and flatbed trailers. Also we can customize the trailers for you, like the drawbar trailers, interlink flatbed or chassis trailers, terminal port skeleton trailer, log trailer and heavy duty multi axle low loader trailers.

1. We have well experienced in reseaching and developing different low bed trailers:2 axle low bed trailer, 3 axle low bed semitrailer, 20 T gooseneck semitrailer, 30 T low bed semitrailer, etc.
2. High quality strength steel Q345B for I-beam
3. Axle: German BPW or FUWA from 12 tons to 20 tons
4. Suspension: Mechanical suspension, air suspension.
5. Tyre: 10.00R20, 10R22.5, 11.00R20, 11R22.5, 12.00R20 or 12R22.5 (Other size is optional)
6. King pin: Optional for 2" or 3.5" Kingpin
7. Twist locks: Standard 4 sets and others for Optional

product Specification

Chengli Special Autombile Co., Ltd, CLW's semi trailers has successfully entered into over 50 countries around the world, such as Ethiopia, Malawi, Uganda, Mali,Zimbabwe, Zambia, Nigeria, Algeria, Sudan, Kenya, Djibouti, India, Pakistan, Argentina, Chile, Mexico, and so on.

3 axle fence trailer
No	ITEM	Unit		Quantity	MODEL
1	Axle	Piece		3	13T FUWA, 220mm width braking pad With 4S/2M ABS, made in China
2	Tyre	Piece		13	11.00R20, with a spare tire
3	Rim	Piece		13	8.0-20
4	Suspension	Set		3	Standard mechanical reinforced type
5	Leaf spring	Set		6	10pcs, 90mm width, 13mm thickness
6	Kingpin	Piece		1	3.5" bolted type.JOST KZ1412
7	Emergency relay valve	Piece		1	WABCO
8	Landing gear	Set		1	28T two sides operation
9	Cross beam				W type, interval space 450mm
10	Chamber			6	T30/30 4 pcs
					30 2 pcs
11	Electrical system	Set		1	Plug 7 lines, 24 volt, LED lights.
Main Specification of Trailer
NO	Specification		Numerical value
1	Overall dimension(LWH)		13000*2550mm Side wall:600mm closed, open downward 600+600 mm mesh, open backward 100mm interval space Intal side wall height 2000mm Each side 6 nos ratchets Front welded small ramp and canvas bracket, tarpaulin rod Detail refer to the confirmed drawing
4	Floor		2 mm flat
			With 6 pcs 6.3# channel pad steel
5	Spare wheel carrier		2 pcs, normal
6	Upper and lower wing-plate thickness		10/10mm, width 146mm
7	Side beam		140mm bending plate, thickness 2.5mm
8	Height of the beam		500mm, web plate thickness:5mm
9	Water tank		1500mm length, ∮550 location designed by the engineer
10	Paint		High quality paint, whole trailer waxed
11	Color		According to your required color code

Landing Gear

Heavy Duty landing gears:
As per the capacity, there are 5ton 8ton, 15ton, 20ton,25ton, 28ton, 30ton and 35ton.
As per the gearbox, there are both Gearbox inside and Gearbox outside type.
As per the operation, there are both Single-Side Operation and Double-Side Operation type.
As per the Sand Shoe, there are T-Shoe, Casting T-Shoe, S-Shoe, R-Shoe and A-Shoe.

King Pin Plate

90# 3.5'' trailer welding king pin
We can provide several model with different specifications.
certification:ISO9001-2000
90# 3.5'' trailer bolt connecting king pin

Axle

1. specifical heat-treat, low-alloy steel axle beam, it has the vitues of good synthetic performance, strong load ability and lower self weight.
2. high quality alloy solid inserted spindle, through wholy heat treatment, provide superior fatigue capability
3. high performance premiun non-asbestos brake linings, extend service life
4. easy for ABS installation
5. camshaft, matching with special seals, can ensure no entry of the grease into the brake drum, more safety
6. new tight fit hub cap have O rings, high property for sealing

Air Suspension

Air Suspension is a type of automotive suspension that uses air springs instead of conventional steel springs. Computer-operated vents on the air springs, suspension sensors, and an on board air compressor allow the system to maintain ride height and vary the suspension's ride characteristics.

Our Service

Quick feedback to solve your questions
Professional engineering and production team
Related Accessories and spare parts offered,no future worries
Regular customer after-sale visiting
Free technical staff training and guidance
Reasonable price and good quality
Quick delivery and shipment

FAQ

Q1: What kinds of fuel delivery truck I can order from your company?
A: There are various sizes of fuel delivery truck with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2: Have you supplied fuel delivery truck to any overseas companies?
A: Yes,with need of cleaning cities,we offered fuel delivery truck to many Africa and south-east Asian countries.

Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q4: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
