FOTON AUMAN 6 Wheeler 10000L Water Spraying Truck With Watering Cannon

Ask Lasest Price
Brand Name :	CLW
Model Number :	CLW20210909
Certification :	ISO9001, CCC, BV, SGS
Price :	Negotiated
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	500 units per month
Delivery Time :	30-35 days after receiving the deposit

Add to Cart

Product Details
Company Profile

FOTON AUMAN 6 Wheeler 10000L Water Spraying Truck With Watering Cannon

FOTON AUMAN 6 wheels 10000L 10Tons Water Spraying Tank Truck Sprinkler Tanker Truck With Watering Cannon

Product Description

Water tank truck is produced for transportation and distribution of industrial and drinking water, spraying and washing of streets and tunnels, dust and environmental control and fire-fighting purposes.In order to achieve those different operations, each water tank truck could be equipped with various components to realize different function.

1. Optional chassis brand of portable water truck: Dongfeng, Isuzu, Sinotruk, FOTON/Forland, Faw, Shacaman, etc.
2. Material of portable water truck: High Tension Steel Q235/Q345,stainless steel 304 for option.
3. Sprinking Width of portable water truck: ≥14M
4. Rear working platform with water cannon range of portable water truck: ≥28M
5. Reliable and high quality water pump

product Specification

Cabin		Left rudder/half row
Whole vehicle main dimensions	Overall dimensions (LxWxH)mm	8255×2460×2820
Whole vehicle main dimensions	Wheel base(mm)	4800
Weight data	Curb weight(kg)	5440
	Gross vehicle weight(kg)	22000
	Persons in cab (persons)	2
Engine	Model	YC6A240-33
	Emissions standards	Euro III
	Displacement(L)	7.255L
	Rated Power	177
	Max torque	900
Gearbox	Model	8JS105TA
Clutch	Type	Single dry diaphragm spring
Front axle	Type	5.5.T
Rear axle	Type/Mainreducetion ratio	10T/4.875
Suspension	Front suspension/Leaf spring number	Non-independent suspension longitudinal plate spring /10
Suspension	Rear suspension/Leaf spring number	Non-independent suspension longitudinal plate spring /10+8
Brake system	Service brake	Drum-type pneumatic brake
Brake system	Parking brake	Barely able to brake
Basic equipment		Hydraulic Turnover/Cruise + 135A.H Battery/Manual Air Conditioners/Tuberless Tire (Inch) 11R22.5/ Manual Doors, Windows and Rearview Mirrors /MP3 / Power Steering/Knit Shock Absorber Seat (Spring)

Technical parameters of sprinkler

tank	volume	10-15m³
	Dimensions	Sectional shape: oval
	Tank material and thickness	Material and thickness of tank body: Q235B carbon steel, 4mm
	Wave breaker	Quantity: 1; Material thickness: Q235B carbon steel, thickness 4mm
	Manhole cover	Quantity: 1 piece; diameter: 500mm; material; aluminum alloy six-jaw can mouth
	Discharge port	1 self-draining port at the tail of the tank; 1 pressure drain on one side of the tank; 1 fire hydrant interface;
	Climb the ladder	Install independent climbing ladder at the end of the tank
	Top guard	Install hand guards on both sides of the tank top
	Level gauge	The front part of the tank, plexiglass
	Tube box	Number: 2; Installation location: 1 each on the left and right sides of the tank Water diversion pipe: each pipe box has a built-in water diversion pipe, the length of the tank body is equal, with stainless steel male and female end joints
Water pump	model	Hangzhou Weilong 65QZ-40/45N stainless steel self-priming sprinkler pump
	Limited Date	40m³/h
	lift	45m
	Water absorption depth	6.5m
Spraying device	control method	manual
	Spray type	Front flush, side spray, back spray
	Sprinkler width	not lower than 14m
	Spray gun range	not lower than 28m
Work platform	position	Rear of the tank

More Pcitures for FOTON AUMAN 6 wheels 10000L 10Tons Water Spraying Tank Truck Sprinkler Tanker Truck

With Watering Cannon

Front , Side and Rear spraying for Water Sprinkler Truck:

Different Capacity of Water Tanker:

Warranty

1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.

The CLW group, which was appointed by the Development and Reform Committee of China. ChengLi is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.

Certificate: ASM, ISO, BV, SGS, CCC etc.
12 independents workshops.
1000 sets of equipment, 25 assemble lines.
300 senior engineers and technicians. About 8000 workers.
800kinds of LPG, trucks and semi-trailers.
20 years wholesale experience
Turnover 250 million and Export 20million annually
Turnover 2 billion trucks and semi-trailers annually.
LPG/Truck Sold to 90 countries
Cooperates DONGFENG,SINOTRUCK,ISUZU,FOTON,FAW,BEIBEN,ETC
