    ISO9001 40CBM Aluminum Alloy Palm Crude Oil Tank Semi Trailer With Pump

    Ask Lasest Price
    Brand Name : CLW
    Model Number : CLW2021060720
    Certification : ISO9001, CCC, BV, SGS
    Price : Negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 units per month
    Delivery Time : 30-35 days after receiving the deposit
    • Product Details
    • Company Profile

    ISO9001 40CBM Aluminum Alloy Palm Crude Oil Tank Semi Trailer With Pump


    Description:
    ** Tank material could be carbon steel, stainless steel, alluminum...
    ** It can be divided into many compartments to load different types of fuels.
    ** BPW axles, JOST kingpin, JOST landing gears, Air suspension, ABS.
    ** Heat preservation of rock cotton or polyurethane foaming, Heating system.
    ** Bottom loading system can be equipped: API connections, over-fill detection system , vapor recovery vent, vapor recovery adaptors & dust cap, pneumatic control, bottom emergent valve...
    ** Tube or tubeless tyres, off-road single tyre for bad roads.


    1. Purpose: It used for transporting all kinds of chemical liquid such as diesel and gasoline etc.
    2. Main parts: Axle, Bottom valve, pipeline and liquid line.
    3. Tank material for optional: Carbon steel, Stainless steel 304, Stainless steel 316, Stainless steel 316L and Aluminium alloyetc.
    4. Available tank volume: 38CBM - 60CBM/2 Axles/3 Axles/4 Axles
    5. Axle brand: China famous brand FUWA/China brand L1/Germany brand BPW.


    product Specification


    Liquid Fuel / Water Tank Truck Semi Trailer
    Dimension(Optional)Axle No.Rated Load (kg)Tire No.Tire Size
    10000-30000liters/10-30cbm2400008825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier)
    30000-60000liters/30-60cbm36000012
    Above 60000liters/60cbm47500016
    ManufactureQingdao Eleph Industry & Trade Co., Ltd
    Wheel Base (mm)1310
    leaf-spring Pcs10
    Axle13/16/18 T
    SuspensionHeavy Duty Mechanic Suspension with Leaf Springs
    Main Beam MaterialQ345B manganese plates, automatic submerged arc welded
    Brake SystemDual line braking system with automatic braking system/chambers
    Brake Air ChamberDouble Model
    Kingpin2' or 3.5' Interchangeable
    Landing gear28T loading capacity with 80T static lifting capacity.
    Tanker body5mm , sealing end: 6mm
    Brake SystemDual Lines Braking System With Automatic Air Chambers
    Brake Air ChamberFour double and two single chamber
    Electrical System24V, 7core socket, lights according to European standards.

    Mainbeam Size

    Upper plate14mm
    Lower plate16mm
    Mid Web8 mm
    Height500-520mm
    Tool Box1 box of standard tools
    Spare tire carrier2 sets
    Color and LogoDepends on the buyer’s requirement.
    Pin HeightAccording to the height of the tractor saddle.
    PaintingThree coats painting; Any color will be available
    Manhole2pcs
    Body MaterialCarbon Steel/ Stainless Steel/Aluminium
    LaddersSteel with anti slipper walking way
    Fire extinguisher2x 4kgs
    handrailSteel, manual
    ApplicationFor liquid transportation

    Warranty


    1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
    2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
    3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.



    FAQ


    Q: Can I buy a sample of your product for testing?

    A. Yes, that's fine. Our MOQ is 1set.


    Q: What's about the payment?

    A: 40% deposit by T/T before order,balanced by T/T before delivery.


    Q: How about quality of your factory product ?

    A: Our product quality is ahead of other manufacturers in the industry. We have advanced production equipment ,skilled workers and perfect mangement quality. So the quality is under control. Our products are certificated by ISO 9001:2008,CCC and BV, and many trucks passed SGS inspection .


    Q: How do you gurantee the quality of the product?

    A: Don't worry, my dear client. Any one of you is very important to us. So we will do inspect all of the goods before shipment. And we had joined the trade credit insurance system. If the product received has quality problems, Alibaba will return the advance payment back to you.

    Q: Why do you choose us?

    A: We are self-produced and self-selling manufacturer and we have more than 15 years of production experience, our products have been sold all over the world.

    Q: What about your after-sale service?
    A: We offer 1 year after-sale service. We can supply the spare parts at factory price all the time.


    Q: Can we visit your factory before purchasing?
    A: We welcome you to visit our factory any time and we will show you our production line .
