Sinotruck HOWO 6X6 371HP 20T 30T Off Road Wrecker

Ask Lasest Price
Brand Name :	CLW
Model Number :	CLW20210615
Certification :	CCC, ISO9001
Price :	Negotiated
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	50 units per Month.
Delivery Time :	40 working days

Add to Cart

Product Details
Company Profile

Sinotruck HOWO 6X6 371HP 20T 30T Off Road Wrecker

Sinotruck HOWO 6x6 371hp 20 tons 30 tons All Wheel Drive Off Road Wrecker Truck Emergency Recovery Wrecker Truck

Product Description:

1. Purpose of Recovery Truck: wrecker/recovery truck/towing truck is used for towing break-down cars or vehicle or bus or trailers on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
2. Optional brand of Recovery Truck :howo,Dongfeng,Isuzu,JAC,JMC,Foton,Shacman...
3. Spare parts of Recovery Truck : Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
4. Capacity range of Recovery Truck:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
5. Fifth wheel attachment is optional for towing trailers as follows

Feature

-- Powerful howo 6X6 off road truck chassis;

-- 360 ° rotation rotator towing truck;

-- Italy hydro control control valve and balance valve;

-- Wuxi oil hydraulic pneumatic equipment co ltd;

-- One-step modeling compartment plate by germany 3P2A punching machine;

-- Adopting American wrecker design and manufacturing technology.

-- Key components using the finite element stress analysis (CAE technology)

-- Adopting high quality high-strength steel for important components

-- Hydraulic technology adopts two filtration systems to ensure hydraulic clean.

-- The key hydraulic lines seals imported from Germany.

-- All cylinders directly installed locking valve, the middle without connecting hose (to prevent bursting), increases safety consumption of gas leads out by protection valve, ensuring the safety of vehicle braking systems.

-- Equipped with various fork lifts (including leaf spring forks).

-- High and low fork combined with various fork lifts.

-- Corbel can be tilted upward with a load, also can be adjusted by the trailer hold angle.

-- Rear brake with pneumatic quick connector, enabling synchronization with towed vehicle braking.

-- Boom with 360 degree continuous rotation.

-- Equipped with trailer towing disk, remote control is optional.

Specification:

Special Device For 20tons Wrecker System
Hoisting Organ	Max hoisting weight(kg)	7400
	Max Hoisting Weight under all extension(kg)	4000
	Max Under-hoisting Capacity (kg)	16000
	Max Under-hoist length (mm)	1600
	Extension Distance of oil Cylinder(mm)	2800
	Under hoisting work angle(°)	-10~2°
Lifting Organ	Max lifting capacity(kg)	20000
	Basic arm length(mm)	5393
	Total arm length(mm)	11393
	Telescope length(mm)	6000
	Max lifting height(mm)	11500
	Crane lifting angle	0°~ 60°
	Crane rotation angle	360°
Winch	Quantity	2
	Max. Pulling power	15000kgs*2
	Winch rated hoisting force(KN)	150×2
	Steel rope	50M length,Φ22mm
Landing Leg	Quantity	4
	Type of front Landing leg	H Type
	Type of rear Landing leg	L Type
	Max Under-hoisting Capacity (kg)	2494
	Distance between rear legs(mm)	4650
Equipped	Four sets of steel fork, a set of tow-fork sleeve, a set of steel plate hanging lug fork, a set of ABS device. A long warning light. Auxiliary light set, auxiliary pipe assembly

CLW group, which was appointed by the Development and Reform Committee of China is a professional company who deal in
different kinds of special vehicles, trailers and construction machinery.

Certificate: ASME, ISO, BV, SGS, CCC etc.
More than 30 independents workshops.
1000 sets of equipment, 25 assemble lines.
300 senior engineers and technicians. About 8000 workers.
800kinds of LPG, trucks and semi-trailers.
20 years wholesale experience
Turnover 250 million and Export 20million annually
Turnover 2 billion trucks and semi-trailers annually.
Trucks and trailers Sold to 90 countries
Cooperates DONGFENG,SINOTRUCK,ISUZU,FOTON,FAW,BEIBEN,ETC

Sales Service

① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
